# Programming Exercise

## Overview

Conducting a programming exercise consists of 7 steps distributed among instructor, Artemis and students:

1. Instructor prepares exercise: Set up a repository containing the exercise code and test cases, build instructions on the CI server, and configures the exercise in Artemis.

2. Student starts exercise: Click on start exercise on Artemis which automatically generates a copy of the repository with the exercise code and configures a build plan accordingly.

3. Optional: Student clones repository: Clone the personalized repository from the remote VCS to the local machine.

4. Student solves exercise: Solve the exercise with an IDE of choice on the local computer or in the online editor.

5. Student uploads solution: Upload changes of the source code to the VCS by committing and pushing them to the remote server (or by clicking submit in the online editor).

6. CI server verifies solution: verify the student’s submission by executing the test cases (see step 1) and provide feedback which parts are correct or wrong.

7. Student reviews personal result: Reviews build result and feedback using Artemis. In case of a failed build, reattempt to solve the exercise (step 4).

8. Instructor reviews course results: Review overall results of all students, and react to common errors and problems.

The following activity diagram shows this exercise workflow.

## Setup

The following sections describe the supported features and the process of creating a new programming exercise.

### Features

Artemis and its version control and continuous integration infrastructure is independent of the programming language and thus supports teaching and learning with any programming language that can be compiled and tested on the command line. Instructors have a lot of freedom in defining the environment (e.g. using build agents and Docker images) in which student code is executed and tested. To simplify the setup of programming exercises, Artemis supports several templates that show how the setup works. Instructors can still use those templates to generate programming exercises and then adapt and customize the settings in the repositories and build plans.

• The support for a specific programming language templates depends on the used continuous integration system. The table below gives an overview:

Programming Language

Bamboo

Jenkins

Java

yes

yes

Python

yes

yes

C

yes

yes

yes

yes

Kotlin

yes

no

VHDL

yes

no

Assembler

yes

no

Swift

yes

yes

OCaml

yes

no

• Not all templates support the same feature set. Depending on the feature set, some options might not be available during the creation of the programming exercise. The table below provides an overview of the supported features:

Programming Language

Sequential Test Runs

Static Code Analysis

Plagiarism Check

Package Name

Project Type

Solution Repository Checkout

Testwise Coverage Analysis

Java

yes

yes

yes

yes

yes

no

yes

Python

yes

no

yes

no

no

no

no

C

no

yes

yes

no

no

no

no

C (FACT framework)

no

no

yes

no

no

no

no

yes

no

no

no

no

yes

no

Kotlin

yes

no

yes

yes

no

no

yes

VHDL

no

no

no

no

no

no

no

Assembler

no

no

no

no

no

no

no

Swift

no

no

yes

no

no

no

no

OCaml

no

no

no

no

no

yes

no

• Sequential Test Runs: Artemis can generate a build plan which first executes structural and then behavioral tests. This feature can help students to better concentrate on the immediate challenge at hand.

• Static Code Analysis: Artemis can generate a build plan which additionally executes static code analysis tools. Artemis categorizes the found issues and provides them as feedback for the students. This feature makes students aware of code quality issues in their submissions.

• Plagiarism Checks: Artemis is able to automatically calculate the similarity between student submissions. A side-by-side view of similar submissions is available to confirm the plagiarism suspicion.

• Package Name: A package name has to be provided

• Solution Repository Checkout: Instructors are able to compare a student submission against a sample solution in the solution repository

• Testwise Coverage Analysis: Artemis can generate a build plan which additionally executes a testwise coverage analysis. Artemis aggregates the recorded data into different metrics. This feature allows instructors to check which code in the solution submission is how often executed by the test cases.

Note

Only some templates for Bamboo support Sequential Test Runs at the moment.

Note

Static Code Analysis for C exercises is only supported for Bamboo at the moment.

Note

Testwise Coverage Analysis is only supported for Bamboo and exercises with regular test runs at the moment.

Note

Instructors are still able to extend the generated programming exercises with additional features that are not available in one specific template.

Note

Documentation for FACT framework can be found here: https://fact.readthedocs.io/en/latest/

We encourage instructors to contribute improvements to the existing templates or to provide new templates. Please contact Stephan Krusche and/or create Pull Requests in the GitHub repository.

### Exercise Creation

1. Open Course Management

• Open

• Navigate into Exercises of your preferred course

1. Generate programming exercise

• Click on Generate new programming exercise

• Artemis provides various options to customize programming exercises:

• Title: The title of the exercise. It is used to create a project on the VCS server for the exercise. Instructors can change the title of the exercise after its creation.

• Short Name: Together with the course short name, the exercise short name is used as a unique identifier for the exercise across Artemis (incl. repositories and build plans). The short name cannot be changed after the creation of the exercise.

• Preview: Given the short name of the exercise and the short name of the course, Artemis displays a preview of the generated repositories and build plans.

• Auxiliary Repositories: Instructors can add auxiliary repositories with a name, checkout directory and description. These repositories are created and added to the build plan when the exercise is created. Auxiliary repositories cannot be changed after the creation of the exercise.

Note

Auxiliary repositories are checked out to the specified checkout directory during the automatic testing of a student submission in case the checkout directory is set. This can be used e.g. for providing additional resources or overwriting template source code in testing exercises.

• Categories: Instructors can freely define up to two categories per exercise. The categories are visible to students and should be used consistently to group similar kinds of exercises.

• Difficulty: Instructors can give students information about the difficulty of the exercise.

• Mode: The mode determines whether students work on the exercise alone or in teams. Cannot be changed after the exercise creation.

• Team size: If Team mode is chosen, instructors can additionally give recommendations for the team size. Instructors/Tutors define the teams after the exercise creation.

• Programming Language: The programming language for the exercise. Artemis chooses the template accordingly. Refer to the programming exercise features for an overview of the supported features for each template.

• Project Type: Determines the project structure of the template. Not available for all programming languages.

• With exemplary dependency: Adds an external Apache commons-lang dependency to the generated project as an example how maven dependencies should be used with Artemis exercises. Only available for Java exercises.

• Package Name: The package name used for this exercise. Not available for all programming languages.

• Release Date: Release date of the exercise. Students will only be able to participate in the exercise after this date.

• Automatic Tests: Every commit of a participant triggers the execution of the tests in the Test repository. Excluded are tests, which are specified to run after the due date. This is only possible if Run Tests once after Due Date has been activated. The tests that only run after the due date are chosen in the grading configuration.

• Due Date: The deadline for the exercise. Commits made after this date are not graded.

• Complaint on Automatic Assessment: This option allows students to write a complaint on the automatic assessment after the due date.

This option is only available if complaints are enabled in the course or the exercise is part of an exam.

Note

Students can still commit code and receive feedback after the exercise due date, if manual review and complaints are not activated. The results for these submissions will not be rated.

• Run Tests once after Due Date: Activate this option to build and test the latest in-time submission of each student on this date. This date must be after the due date. The results created by this test run will be rated.

• Manual Review: Instructors/Tutors have to manually review the latest student submissions after the automatic tests were executed.

• Assessment Due Date: The deadline for the manual reviews. On this date, all manual assessments will be released to the students.

• Example Solution Publication Date: The date when the solution repository becomes available to download for students. If left blank, example solutions are never published.

• Should this exercise be included in the course / exam score calculation?

• Yes: Instructors can define the maximum achievable Points and Bonus points for the exercise. The achieved total points will count towards the total course/exam score

• Bonus: The achieved Points will count towards the total course/exam score as a bonus.

• No: The achieved Points will not count towards the total course/exam score.

• Submission Policy: Configure an initial submission policy for the exercise. The submission policy defines the effect that a submission has on the participation of one participant in a programming exercise. You can choose between 3 different types of submission policies: None, Lock Repository, Submission Penalty. Those policies can be used to limit how many times student can submit their code and receive feedback from automated tests. The feature and configuration is independent from programming language settings and works in combination with static code analysis penalties. Detailed information about the different types of policies and their respective setup can be found in the section configuring submission policies.

Note

Submission policies can only be edited on the Grading Page of the programming exercise after the initial exercise generation.

• Enable Static Code Analysis: Enable static code analysis for the exercise. The build plans will additionally execute static code analysis tools to find code quality issues in the submissions. This option cannot be changed after the exercise creation. Artemis provides a default configuration for the static code analysis tools but instructors are free to configure the static code analysis tools. Refer to the programming exercise features to see which programming languages support static code analysis.

• Max Static Code Analysis Penalty: Available if static code analysis is active. Determines the maximum amount of points that can be deducted for code quality issues found in a submission as a percentage (between 0% and 100%) of Points. Defaults to 100% if left empty. Further options to configure the grading of code quality issues are available in the grading configuration.

Note

Given an exercise with 10 Points. If Max Static Code Analysis Penalty is 20%, at most 2 points will be deducted from the points achieved by passing test cases for code quality issues in the submission.

• Grading Instructions: Available if Manual Review is active. Create instructions for the manual assessment of the exercise.

• Sequential Test Runs: Activate this option to first run structural and then behavior tests. This feature allows students to better concentrate on the immediate challenge at hand. Not supported together with static code analysis. Cannot be changed after the exercise creation.

• Check out repository of sample solution: Activate this option to checkout the solution into the ‘solution’ path. This option is useful to compare the student’s submission with the sample solution. This option is not available for all programming languages.

• Allow Offline IDE: Allow students to clone their personal repository and work on the exercise with their preferred IDE.

• Allow Online Editor: Allow students to work on the exercise using the Artemis Online Code Editor.

• Record Testwise Coverage: Activate this option to record the testwise coverage for the solution repository. This option is only available for Java/Kotlin-exercises with non-sequential test runs.

Note

At least one of the options Allow Offline IDE: and Allow Online Editor: must be active

• Show Test Names to Students: Activate this option to show the names of the automated test cases to the students. If this option is disabled, students will not be able to visually differentiate between automatic and manual feedback.

• Publish Build Plan: Allow students to access and edit their personal build plan. Useful for exercises where students should configure parts of the build plan themselves.

• Click on to create the exercise

Result: Programming Exercise

Artemis creates the repositories:

• Template: template code, can be empty, all students receive this code at the beginning of the exercises

• Test: contains all test cases, e.g. based on JUnit and optionally static code analysis configuration files. The repository is hidden for students

• Solution: solution code, typically hidden for students, can be made available after the exercise

Artemis creates two build plans

• Template: also called BASE, basic configuration for the test + template repository, used to create student build plans

• Solution: also called SOLUTION, configuration for the test + solution repository, used to manage test cases and to verify the exercise configuration

1. Update exercise code in repositories

• Alternative 1: Clone the 3 repositories and adapt the code on your local computer in your preferred development environment (e.g. Eclipse).

• To execute tests, copy the template (or solution) code into a folder assignment in the test repository and execute the tests (e.g. using maven clean test)

• Commit and push your changes

• Notes for Haskell: In addition to the assignment folder, the executables of the build file expect the solution repository checked out in the solution subdirectory of the test folder and also allow for a template subdirectory to easily test the template on your local machine. You can use the following script to conveniently checkout an exercise and create the right folder structure:

#!/bin/sh
# Arguments:
# $1: exercise short name as specified on Artemis #$2: (optional) output folder name
#
# Note: you might want to adapt the BASE variable below according to your needs

if [ -z "$1" ]; then echo "No exercise short name supplied." exit 1 fi EXERCISE="$1"

if [ -z "$2" ]; then # use the exercise name if no output folder name is specified NAME="$1"
else
NAME="$2" fi # default base URL to repositories; change this according to your needs BASE="ssh://git@bitbucket.ase.in.tum.de:7999/$EXERCISE/$EXERCISE" # clone the test repository git clone "$BASE-tests.git" "$NAME" && \ # clone the template repository git clone "$BASE-exercise.git" "$NAME/template" && \ # clone the solution repository git clone "$BASE-solution.git" "$NAME/solution" && \ # create an assignment folder from the template repository cp -R "$NAME/template" "$NAME/assignment" && \ # remove the .git folder from the assignment folder rm -r "$NAME/assignment/.git/"

• Notes for OCaml: The tests expect to be placed in a folder tests next to a folder assignment containing the submission to test and a folder solution with the solution repository. You can use the following script to conveniently checkout an exercise and create the right folder structure:

#!/bin/sh
# Arguments:
# $1: exercise short name as specified on Artemis #$2: (optional) output folder name
#
# Note: you might want to adapt the BASE variable below according to your needs

# shortname of the course to pick exercises from
PREFIX=

if [ -z "$1" ]; then echo "No exercise short name supplied." exit 1 fi # full name of the exercise to load EXERCISE="$PREFIX$1" if [ -z "$2" ]; then
# use the exercise name if no output folder name is specified
NAME="$1" else NAME="$2"
fi

# default base URL to repositories; change this according to your needs
BASE="ssh://git@bitbucket.ase.in.tum.de:7999/$EXERCISE/$EXERCISE"

# clone the test repository
git clone "$BASE-tests.git" "$NAME/tests"
# clone the template repository
git clone "$BASE-exercise.git" "$NAME/template"
# clone the solution repository
git clone "$BASE-solution.git" "$NAME/solution"

# hardlink the various assignment interfaces to ensure they stay in sync
# the version in the solution repository is authoritative in case of conflict
rm "$NAME/template/src/assignment.mli" rm "$NAME/tests/assignment/assignment.mli"
rm "$NAME/tests/solution/solution.mli" ln "$NAME/solution/src/assignment.mli" "$NAME/template/src/assignment.mli" ln "$NAME/solution/src/assignment.mli" "$NAME/tests/assignment/assignment.mli" ln "$NAME/solution/src/assignment.mli" "$NAME/tests/solution/solution.mli"  To run the tests run the following script in either the solution or template folder: #!/bin/sh dir="$(realpath ./)"

cd .. || exit 1
rm ./assignment
ln -s "\$dir" ./assignment
cd tests || exit 1
./run.sh


It is possible to checkout additional student repositories next to the solution and template folder to run tests on them for manual grading.

• Alternative 2: Open in Artemis (in the browser) and adapt the code in online code editor

• You can change between the different repos and submit the code when needed

Edit in Editor

• Alternative 3: Use IntelliJ with the Orion plugin and change the code directly in IntelliJ

• Check the results of the template and the solution build plan

• They should not have the status

• In case of a result, some configuration is wrong, please check the build errors on the corresponding build plan.

• Hints: Test cases should only reference code, that is available in the template repository. In case this is not possible, please try out the option Sequential Test Runs

1. Optional: Adapt the build plans

• The build plans are preconfigured and typically do not need to be adapted

• However, if you have additional build steps or different configurations, you can adapt the BASE and SOLUTION build plan as needed

• When students start the programming exercise, the current version of the BASE build plan will be copied. All changes in the configuration will be considered

1. Optional: Configure static code analysis tools

• The Test repository contains files for the configuration of static code analysis tools, if static code analysis was activated during the creation/import of the exercise

• The folder staticCodeAnalysisConfig contains configuration files for each used static code analysis tool

• On exercise creation, Artemis generates a default configuration for each tool, which contains a predefined set of parameterized activated/excluded rules. The configuration files serve as a documented template that instructors can freely tailor to their needs.

• On exercise import, Artemis copies the configuration files from the imported exercise

• The following table depicts the supported static code analysis tools for each programming language, the dependency mechanism used to execute the tools and the name of their respective configuration files

Programming Language

Execution Mechanism

Supported Tools

Configuration File

Java

Maven plugins (pom.xml or build.gradle)

Spotbugs

spotbugs-exclusions.xml

Checkstyle

checkstyle-configuration.xml

PMD

pmd-configuration.xml

PMD Copy/Paste Detector (CPD)

Swift

Script

SwiftLint

.swiftlint.yml

C

Script

GCC

Note

The Maven plugins for the Java static code analysis tools provide additional configuration options.

Note

GCC can be configured by passing the desired flags in the tasks. For more information, see GCC Documentation.

• The build plans use a special task/script for the execution of the tools

Note

Instructors are able to completely disable the usage of a specific static code analysis tool by removing the plugin/dependency from the execution mechanism. In case of Maven plugins, instructors can remove the unwanted tools from the pom.xml or build.gradle. Alternatively, instructors can alter the task/script that executes the tools in the build plan. PMD and PMD CPD are a special case as both tools share a common plugin. To disable one or the other, instructors must delete the execution of a tool from the build plan.

1. Adapt the interactive problem statement

• Click the button of the programming exercise or navigate into and adapt the interactive problem statement.

• The initial example shows how to integrate tasks, link tests and integrate interactive UML diagrams

• General Actions

• Save the current grading configuration of the open tab

• Reset the current grading configuration of the open tab to the default values. For Test Case Tab, all test cases are set to weight 1, bonus multiplier 1 and bonus points 0. For the Code Analysis Tab, the default configuration depends on the selected programming language.

• Re-evaluates all scores according to the currently saved settings using the individual feedback stored in the database

• Trigger all build plans. This leads to the creation of new results using the updated grading configuration

• Two badges display if the current configuration has been saved yet and if the grading was changed. The following graphic visualizes how each action affects the grading page state:

Warning

Artemis always grades new submissions with the latest configuration but existing submissions might have been graded with an outdated configuration. Artemis warns instructors about grading inconsistencies with the Updated grading badge.

• Test Case Tab: Adapt the contribution of each test case to the overall score

Note

Artemis registers the test cases defined in the Test repository using the results generated by Solution build plan. The test cases are only shown after the first execution of the Solution build plan.

• On the left side of the page, instructors can configure the test case settings:

• Test Name: Name of the test case as defined in Test repository

• Weight: The points for a test case are proportional to the weight (sum of all weights as the denominator) and are calculated as a fraction of the maximum points

Note

Bonus points for an exercise (implied by a score higher than 100%) are only achievable if at least one bonus multiplier is greater than 1 or bonus points are given for a test case

• Bonus multiplier: Allows instructors to multiply the points for passing a test case without affecting the points rewarded for passing other test cases

• Bonus points: Adds a flat point bonus for passing a test case

• Visibility: Select the visibility of feedbacks to students for this test case.

• Always: Feedback associated with this test case is visible to students directly after the automatic grading process for their submission.

• After Due Date: Feedback associated with this test case is visible to students only after the due date for this exercise has passed. Tutors and Instructors are able to see the feedback before the due date.

If for some students an individual due date is set, the detailed feedback for those tests is invisible to all other students until the exercise submission is no longer possible for all students. Other students can however still see if the tests passed or failed and receive points accordingly, even if the latest individual due has not passed yet.

Warning

For manual assessments all feedback details will be visible to this student, even if the due date has not passed yet for others. Tutors can start the manual assessment for all students with the regular due date as soon as it has passed. Set an appropriate assessment due date in the exercise settings to make sure that students cannot tell still working students about the test case details.

• Never: Feedback associated with this test case is never visible to students even after the due date for this exercise has passed. Tutors and Instructors are able to see the feedback before and after the due date, e.g. when manually assessing submissions. Additionally, results of this test case are not considered in the student score calculation.

• Is Active: Displays whether the test case is currently part of the grading configuration. The Show inactivate test cases controls whether inactive test cases are displayed

• Passed %: Displays statistics about the percentage of participating students that passed or failed the test case

Note

Example 1: Given an exercise with 3 test cases, maximum points of 10 and 10 achievable bonus points. The highest achievable score is $$\frac{10+10}{10}*100=200\%$$. Test Case (TC) A has weight 2, TC B and TC C have weight 1 (bonus multipliers 1 and bonus points 0 for all test cases). A student that only passes TC A will receive 50% of the maximum points (5 points).

Note

Example 2: Given the configuration of Example 1 with an additional bonus multiplier of 2 for TC A. Passing TC A accounts for $$\frac{2*2}{2+1+1}*100=100\%$$ of the maximum points (10). Passing TC B or TC C accounts for $$\frac{1}{4}*100=25\%$$ of the maximum points (2.5). If the student passes all test cases he will receive a score of 150%, which amounts to 10 points and 5 bonus points.

Note

Example 3: Given the configuration of Example 2 with additional bonus points of 5 for TC B. The points achieved for passing TC A and TC C do not change. Passing TC B now accounts for 2.5 points plus 5 bonus points (7.5). If the student passes all test cases he will receive 10 (TC A) + 7.5 (TC B) + 2.5 (TC C) points, which amounts to 10 points and 10 bonus points and a score of 200%.

• On the right side of the page, charts display statistics about the current test case configuration. If changes are made to the configuration, a of the statistics is shown.

• Weight Distribution: The distribution of test case weights. Visualizes the impact of each test case for the score calculation

• Total Points: The percentage of points given to students according to a specific test case. 100% in the chart represents full scores (100%) of all students

• Code Analysis Tab: Configure the visibility and grading of code quality issues on a category-level

Note

The Code Analysis Tab is only available if static code analysis was activated for the exercise.

• Code quality issues found during the automatic assessment of a submission are grouped into categories. Artemis maps categories defined by the static code analysis tools to Artemis categories according to the following table:

Mapping

Category

Description

Java

Swift

C

Code that violates recommended and essential coding practices

Spotbugs I18N

PMD Best Practices

Code Style

Code that is confusing and hard to maintain

Spotbugs STYLE

Swiftlint (all rules)

Checkstyle blocks

Checkstyle coding

Checkstyle modifier

PMD Code Style

Potential Bugs

Coding mistakes, error-prone code or threading errors

Spotbugs CORRECTNESS

GCC Memory

Spotbugs MT_CORRECTNESS

PMD Error Prone

Duplicated Code

Code clones

PMD CPD

Security

Vulnerable code, unchecked inputs and security flaws

Spotbugs MALICIOUS_CODE

GCC Security

Spotbugs SECURITY

PMD Security

Performance

Inefficient code

Spotbugs PERFORMANCE

PMD Performance

Design

Program structure/architecture and object design

Checkstyle design

PMD Design

Code Metrics

Violations of code complexity metrics or size limitations

Checkstyle metrics

Checkstyle sizes

Documentation

Code with missing or flawed documentation

Checkstyle annotation

PMD Documentation

Naming & Format

Rules that ensure the readability of the source code (name conventions, imports, indentation, annotations, white spaces)

Checkstyle imports

Checkstyle indentation

Checkstyle naming

Checkstyle whitespace

Miscellaneous

Uncategorized rules

Checkstyle miscellaneous

GCC Misc

Note

For Swift, only the category Code Style can contain code quality issues currently. All other categories displayed on the grading page are dummies.

Note

The GCC SCA option for C does not offer categories by default. The issues were categorized during parsing with respect to the rules.

• On the left side of the page, instructors can configure the static code analysis categories.

• Category: The name of category defined by Artemis

• State:

• INACTIVE: Code quality issues of an inactive category are not shown to students and do not influence the score calculation

• FEEDBACK: Code quality issues of a feedback category are shown to students but do not influence the score calculation

• GRADED: Code quality issues of a graded category are shown to students and deduct points according to the Penalty and Max Penalty configuration

• Penalty: Artemis deducts the selected amount of points for each code quality issue from points achieved by passing test cases

• Max Penalty: Limits the amount of points deducted for code quality issues belonging to this category

• Detected Issues: Visualizes how many students encountered a specific number of issues in this category

1. Verify the exercise configuration

• Open the page of the programming exercise

• The template result should have a score of 0% with 0 of X passed or 0 of X passed, 0 issues (if static code analysis is enabled)

• The solution result should have a score of 100% with X of X passed or X of X passed, 0 issues (if static code analysis is enabled)

Note

If static code analysis is enabled and issues are found in the template/solution result, instructors should improve the template/solution or disable the rule, which produced the unwanted/unimportant issue.

• Click on

• Below the problem statement, you should see Test cases ok and Hints ok

### Exercise Import

On exercise import, Artemis copies the repositories, build plans, interactive problem statement and grading configuration from the imported exercise.

1. Open Course Management

• Open

• Navigate into Exercises of your preferred course

1. Import programming exercise

• Click on Import Programming Exercise

• Select an exercise to import

Note

Instructors can import exercises from courses, where they are registered as instructors

• Artemis provides special options to update the assessment process

• Recreate Build Plans: Create new build plans instead of copying them from the imported exercise

• Update Template: Update the template files in the repositories. This can be useful if the imported exercise is old and contains outdated dependencies. For Java, Artemis replaces JUnit4 by Ares (which includes JUnit5) and updates the dependencies and plugins with the versions found in the latest template. Afterwards you might need to adapt the test cases.

• Instructors are able to activate/deactivate static code analysis. Changing this option from the original value, requires the activation of Recreate Build Plans and Update Template.

Note

Recreate Build Plans and Update Template are automatically set if the static code analysis option changes compared to the imported exercise. The plugins, dependencies and static code analysis tool configurations are added/deleted/copied depending on the new and the original state of this option.

• Fill out all mandatory values and click on

Note

The interactive problem statement can be edited after finishing the import. Some options such as Sequential Test Runs cannot be changed on exercise import.

## Static Code Analysis Default Configuration

The following sections list the rules that are active for the default static code analysis configuration.

### Java

1. Spotbugs

All tool categories and their rules are active by default except for the NOISE and EXPERIMENTAL category. Refer to the Spotbugs documentation for a description of all rules.

1. Checkstyle

For a description of the rules refer to the Checkstyle documentation.

Category (Tool/Artemis)

Rule

Properties

Coding/Code Style

EmptyStatement

EqualsHashCode

HiddenField

ignoreConstructorParameter=”true”

ignoreSetter=”true”

setterCanReturnItsClass=”true”

IllegalInstantiation

InnerAssignment

MagicNumber

MissingSwitchDefault

MultipleVariableDeclarations

SimplifyBooleanExpression

SimplifyBooleanReturn

Class Design/Design

FinalClass

HideUtilityClassConstructor

InterfaceIsType

VisibilityModifier

Block Checks/Code Style

AvoidNestedBlocks

EmptyBlock

NeedBraces

Modifiers/Code Style

ModifierOrder

RedundantModifier

Size Violations/Code Metrics

MethodLength

ParameterNumber

FileLength

LineLength

max=”120”

Imports/Naming & Formatting

IllegalImport

RedundantImport

UnusedImports

Naming Conventions/Naming & Formatting

ConstantName

LocalFinalVariableName

LocalVariableName

MemberName

MethodName

ParameterName

TypeName

Whitespace/Naming & Formatting

GenericWhitespace

NoWhitespaceAfter

NoWhitespaceBefore

OperatorWrap

WhitespaceAfter

WhitespaceAround

allowedAnnotations=”Override,Test”

tokens=”METHOD_DEF,ANNOTATION_FIELD_DEF,COMPACT_CTOR_DEF”

Miscellaneous/Miscellaneous

ArrayTypeStyle

UpperEll

NewlineAtEndOfFile

Translation

1. PMD

For a description of the rules refer to the PMD documentation.

Category (Tool/Artemis)

Rule

AvoidUsingHardCodedIP

CheckResultSet

UnusedImports

UnusedFormalParameter

UnusedLocalVariable

UnusedPrivateField

UnusedPrivateMethod

Code Style/Code Style

DontImportJavaLang

DuplicateImports

ExtendsObject

ForLoopShouldBeWhileLoop

TooManyStaticImports

UnnecessaryFullyQualifiedName

UnnecessaryModifier

UnnecessaryReturn

UselessParentheses

UselessQualifiedThis

Design/Design

CollapsibleIfStatements

SimplifiedTernary

UselessOverridingMethod

Error Prone/Potential Bugs

AvoidBranchingStatementAsLastInLoop

AvoidDecimalLiteralsInBigDecimalConstructor

AvoidMultipleUnaryOperators

AvoidUsingOctalValues

BrokenNullCheck

CheckSkipResult

ClassCastExceptionWithToArray

DontUseFloatTypeForLoopIndices

EmptyCatchBlock

EmptyFinallyBlock

EmptyIfStmt

EmptyInitializer

EmptyStatementBlock

EmptyStatementNotInLoop

EmptySwitchStatements

EmptySynchronizedBlock

EmptyTryBlock

EmptyWhileStmt

ImportFromSamePackage

JumbledIncrementer

MisplacedNullCheck

OverrideBothEqualsAndHashcode

ReturnFromFinallyBlock

UnconditionalIfStatement

UnnecessaryConversionTemporary

UnusedNullCheckInEquals

UselessOperationOnImmutable

DoubleCheckedLocking

Performance/Performance

BigIntegerInstantiation

BooleanInstantiation

Security/Security

All rules

1. PMD CPD

Artemis uses the following default configuration to detect code duplications for the category Copy/Paste Detection. For a description of the various PMD CPD configuration parameters refer to the PMD CPD documentation.

<!-- Minimum amount of duplicated tokens triggering the copy-paste detection -->
<minimumTokens>60</minimumTokens>
<!-- Ignore literal value differences when evaluating a duplicate block.
If true, foo=42; and foo=43; will be seen as equivalent -->
<ignoreLiterals>true</ignoreLiterals>
<!-- Similar to ignoreLiterals but for identifiers, i.e. variable names, methods names.
If activated, most tokens will be ignored so minimumTokens must be lowered significantly -->
<ignoreIdentifiers>false</ignoreIdentifiers>


### C

GCC

For a description of the rules/warnings refer to the GCC Documentation. For readability reasons the rule/warning prefix -Wanalyzer- is omitted.

Category (Tool/Artemis)

Rule

Memory Management / Potential Bugs

free-of-non-heap

malloc-leak

file-leak

mismatching-deallocation

Undefined Behavior / Potential Bugs

double-free

null-argument

use-after-free

use-of-uninitialized-value

write-to-const

write-to-string-literal

possible-null-argument

possible-null-dereference

double-fclose

too-complex

stale-setjmp-buffer

Security/Security

exposure-through-output-file

unsafe-call-within-signal-handler

use-of-pointer-in-stale-stack-frame

tainted-array-index

Miscellaneous/Miscellaneous

Rules not matching to above categories

Note

GCC output can still contain normal warnings and compilation errors. That will also be added to the Miscellaneous category. Usually it’s best to disable this category, as it contains errors not related to the SCA. Therefore, if the warning/error does not belong to first four above categories it is not an SCA issue as of GCC 11.1.0.

## Submission Policy Configuration

The following sections explains the configuration options for submission policies:

The submission policy defines the effect that a submission has on the participation of one participant in a programming exercise. A programming exercise might have no submission policy at all, or one submission policy, but never more than one. Submission policies are initially specified in the creation process of a programming exercise and can later be adjusted in the grading configuration of the particular programming exercise.

Note

One submission is defined by one push to the exercise participation repository by the participant themself that triggers the automatic tests resulting in feedback for the participant. Automatic test runs triggered by instructors are not considered submissions.

### Submission Policy Configuration & General Information

Choosing the right submission policy configuration depends on the exercise and your teaching style. In general, lock repository and submission penalty policies combat trial-and-error solving approaches.

1. None When selecting no submission policy, exercise participants can submit their solution as often as they want until the deadline.

2. Lock Repository Participants can submit a fixed number of times within the submission period of a programming exercise. Once the participant reaches the submission limit, further participation in the exercise is prevented by locking the participation repository. The participant may still work on their solution locally, but cannot submit it to Artemis to receive feedback.

With the example configuration shown in the figure above, participants can submit their solution 5 times and receive feedback 5 times. After that, Artemis locks the participation repository, so the participant can no longer push their solutions to their repository.

Note

When locking the participation repository upon reaching the submission limit fails for any reason and the participant submits again, Artemis attempts to lock the repository again and sets the newly generated result to .

3. Submission Penalty Participants can submit as often as they want until the deadline, however, for each submission exceeding the submission limit, the exceeding submission limit penalty is deducted from the participant’s score. The exceeding submission limit penalty must be provided as a positive number of points.

With the example configuration shown in the figure above, participants can submit their solution 3 times regularly. For every submission exceeding the limit of 3, 1.5 points are deducted from the participant’s score. The score cannot be negative. For example, when the participant reaches 6 out of 12 points on the 4th submission, 1.5 points are deducted for the one submission exceeding the limit of 3, resulting in a participation score of 4.5 instead of 6 out of 12. On the 5th submission, 3 points are deducted for 2 submissions exceeding the limit. The student receives feedback that explains the deduction.

### Updating Submission Policies

After generating a programming exercise initially, submission policies can be updated and toggled on the grading page of the programming exercise.

1. (De)activating Submission Policies When the submission policy of a programming exercise is active, the button is displayed. When the policy is inactive, the button is displayed instead. The active submission policy of an exercise can be deactivated by pressing . When the policy is deactivated, Artemis will no longer enforce the policy. Repositories that were locked due to the enforcement of the submission policy, get unlocked. Submission policies can be activated again by pressing . When (de)activating a submission penalty policy, must be pressed in order to apply the effect.

2. Updating Submission Policies Submission policies can be updated during the exercise by modifying the configuration and pressing . When updating a policy, the effect of the former policy is removed and the effect of the new policy is applied. When the new policy is a submission penalty policy, must be pressed to update the latest results of all participants.

3. Deleting Submission Policies Submission policies can be deleted by selecting None as submission policy type and pressing . When deleting submission policies, their effect on participations is removed. Every repository that is locked due to a lock repository policy is unlocked and the participant can continue working on the exercise. When deleting a submission penalty policy, must be pressed in order to revert the submission policy effect.

## Online Editor

The following screenshot shows the online code editor with interactive and dynamic exercise instructions on the right side. Tasks and UML diagram elements are referenced by test cases and update their color from red to green after students submit a new version and all test cases associated with a task or diagram element pass. This allows the students to immediately recognize which tasks are already fulfilled and is particularly helpful for programming beginners.

### Display of hidden files

The online editor displays only visible files, to avoid showing for example .git and .gitignore config files. This also means that other config files, like SwiftLint’s .swiftlint.yml file, are not shown. Those files currently can only be accessed via your own IDE.

## Testing with Ares

Ares is a JUnit 5 extension for easy and secure Java testing on Artemis.

Its main features are

• a security manager to prevent students crashing the tests or cheating

• more robust tests and builds due to limits on time, threads and io

• support for public and hidden Artemis tests, where hidden ones obey a custom deadline

• utilities for improved feedback in Artemis like processing multiline error messages or pointing to a possible location that caused an Exception

• utilities to test exercises using System.out and System.in comfortably

## Best practices for writing test cases

The following sections describe best practices for writing test cases. The examples and explanations are specifically written for Java (using Ares/JUnit5), but the practices can also be generalized for other programming languages.

### General best practices

• Write Meaningful Comments for your Tests

These comments should contain information about what is tested specifically, which task from the problem statement is addressed or which TODO (if there are numbered TODOs in the template), how many points this test is worth when passed and more if necessary. But make sure to keep the information consistent with the settings on Artemis like the weight of each testcase.

/**
* Tests that borrow() in Book successfully sets the available attribute to false
* Problem Statement Task 2.1
* Worth 1.5 Points (Weight: 1)
*/
@Test
public void testBorrowInBook() {
// Test Code
}


Better yet, for manual correction, use these comments in the display name of the test. This allows the assessors, who execute the tests in the IDE, to have more meaningful names displayed. The following example would make counting points easier.

@DisplayName("1.5 P | Books can be borrowed successfully")
@Test
public void testBorrowInBook() {
// Test Code
}

• Use Appropriate and Descriptive Names for Test Cases

After exercises and exams, test names will be used to create statistics. If the tests are called test1, test2, test3, it will be hard to read those statistics. This is the same reason as to why you should not name your variables int a, double b, String c. For example, if you want to test the method borrow in the class Book, testBorrowInBook() would be an appropriate name for the test case.

@Test
public void testBorrowInBook() {
// Test Code
}


If you have many tests in different (nested) classes that are not completely distinct, add the name of the tested class to the test to avoid having two tests with the same names. For example, if you test both add methods of a LinkedList and an ArrayList. Having the same test name will lead to errors on Artemis. Clearer test names also makes it easier to read and configure the grading in Artemis.

@Test
// Test Code
}


Hint

For Java exercises: If all test methods are in a single class this is not necessary, because the Java compiler won’t allow multiple methods with override-equivalent signatures.

• Use Appropriate Timeouts for Test Cases

For regular test cases, using a @StrictTimeout(1) annotation is enough. This represents a strict timeout of one second. The value type of the strict timeout annotation defaults to seconds. If you need a shorter timeout, you can use @StrictTimeout(value = 500, unit = TimeUnit.MILLISECONDS). This annotation can also be added over a test class. In that case the timeout applies individually to every test in that class.

@Test
@StrictTimeout(1)
public void testBorrowInBook() {
// Test Code
}


Note

When defining timeouts, you should take into account that the tests are run on a Continuous Integration Server (using build agents). The tests will most likely execute a lot faster on your local machine.

• Avoiding Assert Statements

Instead use conditional fail() calls to hide confusing information from the students. This could be considered a bad practice in regular testing but it helps to create fail messages that are less confusing, especially for beginners. Additionally, this also hides information about test implementation details, if the specific inputs or expected outputs should stay unknown to students.

@Test
public void testBorrowInBook() {
Object book = newInstance("Book", 0, "Some title");
invokeMethod(book, "borrow");
assertFalse((Boolean) invokeMethod(book, "isAvailable"), "A borrowed book must be unavailable!");
}


If the student fails the test, Artemis will display something like org.opentest4j.AssertionFailedError: A borrowed book must be unavailable! ==> Expected <false> but was <true>. The part after ‘==>’ should not be shown to the student as it contains implementation detail.

@Test
public void testBorrowInBook() {
Object book = newInstance("Book", 0, "Some title");
invokeMethod(book, "borrow");
if ((Boolean) invokeMethod(book, "isAvailable")) {
fail("A borrowed book is not available anymore!");
}
}


This will just display the message ‘org.opentest4j.AssertionFailedError: A borrowed book is not available anymore!’, which focuses, except for the first part, on the actual error instead of test internals.

• Write Tests that are as Independent of the Student’s Code as Possible

Students can break everything and will break everything. Avoid direct code references and use reflective operations instead. That way if a student modifies the template by accident and the test code would normally not compile, they still get more meaningful feedback than a simple build error.

@Test
public void testBorrowInBook() {
Book book = new Book(0, "Some title");
book.borrow();
if (book.isAvailable()) {
fail("A borrowed book must be unavailable!");
}
}


The code above will lead to a build error, if the student accidentally changes the Book class. Test code build errors usually have a cryptic fail messages and it should be avoided that students see those confusing error messages.

@Test
public void testBorrowInBook() {
Object book = newInstance("Book", 0, "Some title");
invokeMethod(book, "borrow");
if ((Boolean) invokeMethod(book, "isAvailable")) {
fail("A borrowed book must be unavailable!");
}
}


The code above will lead to an error message like The class ‘Book’ was not found within the submission. Make sure to implement it properly. The message is clear and tells the student exactly what is wrong with their code.

• Check for Hard-Coded Student Solutions

It is possible that students hardcode values to pass a certain set of tests. Therefore, you should check whether this is the case or not. This is especially important in an exam setting, so students don’t get awarded points for a solution that does not fulfill the requirements described in the problem statement.

• Avoid Relying on a Specific Order in which Students Solve the Tasks

Tests should successfully cover one aspect of the submission without requiring the implementation of a different part of the exercise, even if those aspects are heavily coupled.

In this example, the student is supposed to expand the translate method first and after that the runService method:

public String translate(String word, String language) {
return switch (language) {
case TranslationService.LANGUAGE_GERMAN -> translateToGerman(word);
// TODO: Add a case for the French language
default -> throw new IllegalStateException("Illegal language requested: " + language);
};
}

public String runService(String serviceName, String parameter) {
String result = null;
if (serviceName.equals(TranslationService.SERVICE_NAME_TRANSLATION_GERMAN)) {
result = translate(parameter, TranslationService.LANGUAGE_GERMAN);
}
// TODO: Add a case for the French language
else {
System.out.println("Can't offer service " + serviceName);
}
return result;
}


There are two separate tests, one testing the translation and the other one testing the runService method. The test for runService must not assume that the translate method is already implemented correctly. A possible solution for this problem could look like this:

@Test
public void testRunServiceInTranslationServer() {
TranslationServer testTranslationServer = new TranslationServer() {
public String translate(String word, String language) {
return word + ":" + language;
}
}
String expected = "Dog:French";
String actual = testTranslationServer.runService("French", "Dog");
if(!expected.equals(actual)) fail("Descriptive fail message");
}


This test correctly checks, if the student added the case for the French language and called the appropriate method with the appropriate parameters. Because the translation method was overridden, it doesn’t matter whether the student has already completed the previous task or not.

Note

If you use the this technique, you should have some way to deal with students that make the class or method final, either via problem statement or test. Otherwise students get compilation errors in the test code.

• Catch Possible Student Errors

Handle possible student mistakes appropriately in the test case. For example, if a method of the student returns null and this is not handled appropriately in the test, this might produce a NullPointerException, which will lead to a cryptic fail message. A null check in the test case allows providing a more clear fail message to the student.

### Java best practices

• Use Constant String Attributes to Represent the Base Package

Some courses use long package identifiers like de.tum.in.ase.pse. When instantiating objects with reflections, the instantiation method usually takes the full canonical name of a class, which is de.tum.in.ase.pse.Book for example. To avoid writing out this full canonical name all the time, you can add a constant String attribute representing the base package name to the top of your test class.

private static final String BASE_PACKAGE = "de.tum.in.ase.pse.";

@Test
public void testBorrowInBook() {
Object book = newInstance(BASE_PACKAGE + "Book", 0, "Some title");
// Test Code
}

• Use JUnit5 and Ares Features

More information can be found in the JUnit5 and Ares documentation. The following list adds some useful notes:

• Use Nested Tests to group tests

In combination with display names for both tests and the nested classes, this allows to structure grading with tests and the grouping is also helpful when executing the test in the IDE. One example would be to structure the tests by exercise sub-tasks or to group tests that all check a single more complicated method. You can also do this by using static nested classes instead of inner classes annotated with @Nested (decide depending on your scenario).

• Define a custom, well-structured and predictable test execution order with @Order

• If you test multiple cases in a single test (e.g. because you want “all or nothing” grading for those cases or simply check with multiple inputs), you can use assertDoesNotThrow to pass a message that is displayed in Artemis, in case an exception occurs in the student code.

• If you want to test multiple assertions that are fairly independent in a single test (e.g. because you want “all or nothing” grading for those cases or simply check with multiple inputs) you should consider if assertAll is what you need. This will execute all passed executables and aggregate the failures, which allows showing students multiple wrong aspects of their solution directly.

• If you have special needs, consider using Dynamic Tests and/or write your own extension.

• If you need to test tests, use the JUnit Platform Test Kit. For providing wrong implementations that students need to test, consider

• passing interface implementations (easiest and safe) → pure Java

• pass mocked objects (flexible and safe, students don’t need to know) → EasyMock/Mockito

• mock single methods of tested objects (partial mock) or mock constructors → one of the above plus PowerMock

• Define your own Annotations

Own annotations are an easy and powerful tool that keeps your code readable. This example defines an annotation that combines both test and strict timeout.

@Test
@StrictTimeout(10)
@Retention(RetentionPolicy.RUNTIME)
@Target({ElementType.METHOD})
public @interface LongTest {

}

• Consider using jqwik for Property-Based Testing

Jqwik allows testing with arbitrary inputs and shrinks the test errors, resulting in excellent counter examples when student code fails (usually exactly the edge case).

• Eclipse Compiler and Best-Effort Compilation

Use the Eclipse Java Compiler for partial, best-effort compilation. This is particularly useful for exam exercises and other more “dirty” programming work. It is also useful for testing complicated generics (you really don’t want to do that with java reflection). This causes compilation errors to be transformed into errors that are thrown where code does not compile. This is done on method and class level (essentially replacing the body of the class/method with throw new Error("Unresolved compilation problems: ..."), which is then thrown whenever the class/method is used).

If you intend to write tests that exploit that, make sure that only the body of the test methods does not compile (e.g. if a student didn’t implement something from a task). If your complete test class does not compile, this causes the complete test class initialization to fail, which results in cryptic feedback in Artemis. Anything in the test class that is not a method body or nested class body must compile. This includes method return types and parameter types, and therefore also lambdas! You can avoid that by using e.g. the Object class and cast inside / at the call site. Use e.g. a nested class for Fields, Field types and Methods with student class return/parameter types that could potentially not compile. Because the nested class is a separate class which is loaded separately, the top level test class will still load successfully and only methods using that nested class will fail due to the error from the nested class initialization.

You can choose to use the Eclipse compiler for both student and test code, or for test code only, depending on whether you want to grade not fully compiling code.

Note

The Eclipse Compiler released under this maven coordinate does not always support the latest Java version. You can still compile student code with the latest Java version and only the test code with the previous.

• Variant: Test Code Only

Test Code Only
<plugin>
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-compiler-plugin</artifactId>
<version>3.8.1</version>
<configuration>
<source>17</source>
<target>17</target>
</configuration>
<executions>
<execution>
<id>default-testCompile</id>
<phase>process-test-sources</phase>
<goals>
<goal>testCompile</goal>
</goals>
<configuration>
<source>17</source>
<target>17</target>
<compilerId>jdt</compilerId>
<optimize>true</optimize>
<failOnError>false</failOnError>
<compilerArguments>
<proceedOnError />
</compilerArguments>
</configuration>
</execution>
</executions>
<dependencies>
<dependency>
<groupId>org.eclipse.tycho</groupId>
<artifactId>tycho-compiler-jdt</artifactId>
<version>2.1.0</version>
</dependency>
</dependencies>
</plugin>

• Variant Student and Test Code:

Variant Student and Test Code
<plugin>
<groupId>org.apache.maven.plugins</groupId>
<artifactId>maven-compiler-plugin</artifactId>
<version>3.8.1</version>
<configuration>
<source>17</source>
<target>17</target>
<compilerId>jdt</compilerId>
<optimize>true</optimize>
<failOnError>false</failOnError>
<compilerArguments>
<proceedOnError />
</compilerArguments>
</configuration>
<dependencies>
<dependency>
<groupId>org.eclipse.tycho</groupId>
<artifactId>tycho-compiler-jdt</artifactId>
<version>2.1.0</version>
</dependency>
</dependencies>
</plugin>

• Common Pitfalls / Problems:

• The Reflection API is limited when it comes to constant attributes. Constant attributes are static final attributes with a primitive or String type. Java inlines such attributes during compile-time, which makes it more or less impossible to change the value during runtime.

• Be careful with long output, arrays or Strings. This might be unreadable in Artemis or even cut of after 5000 characters.

## Sending Feedback back to Artemis

Per default the results of all unit tests are extracted and sent back to Artemis without any further manual interaction needed. Only for some custom setups a semi-automatic approach might be necessary.

### Jenkins

In the Jenkins CI-System the test case feedbacks are extracted from XML-Files in the JUnit format. The Jenkins plugins reads all such files from a folder results in the top level of the Jenkins workspace. The files resulting from the execution of regular executed unit tests are copied to this folder automatically.

To add additional custom test case feedbacks another mechanism is provided by creating a folder customFeedbacks also on the top level of the workspace. In this folder an arbitrary number of JSON-Files can be created. Each one represents a single test case feedback and should have the format: { "name": string, "successful": boolean, "message": string }

• name: This is the name of the test case as it will be shown for example on the ‘Configure Grading’ page. It should therefore have a for this exercise uniquely identifiable name and has to be non-null and not empty.

• successful: Indicates if the test case execution for this submission should be marked as successful or failed. Defaults to false if not present.

• message: The message shown as additional information to the student. Required for non-successful tests/feedback, optional otherwise.
